Jual Gas Turbine Flow Meter SHM Size 12 Inch
Informasi Produk
APPLICATION
Natural Gas, City Gas, Propane, Butane, Air, Nitrogen, and other gases.
Gas Turbine Flow Meter SHM Size 12 Inch ( DN 300mm )
Jual Gas Turbine Flow Meter SHM Size 12 Inch
Gas Turbine Flow Meter SHM
SPECIFICATION
Size : DN 25-300
Material : Head Epoxy Coated Aluminium Body Epoxy Coated Aluminium Flange Epoxy Coated Aluminium.
Temperature : (-20) -60c
Pressure : 16 Bar
Power Supply : Battery 3.6 V/ 24 VCD
Output : Pulse, 4-20 mA, RS 485
Protecction Grade : IP 65
Connection : PN 16
Accuracy : +/-1.5%
Measurement : Refer to Table below
Repeatibility : -
Explosion Proof :-
Waranty 2 years ( full Service & Spare parts )
APPLICATION
Natural Gas, City Gas, Propane, Butane, Air, Nitrogen, and other gases.
