Water Meter Arus

Water Meter Arus

This Range of Water Meter is used to measure the total quantity of cold(hot) potable water which consumed in Industrial
and mining enterprise passing through the pipeline. Compliance with standard : Technical data conforms to ISO 4064 Class
B standard for horizontal installation.
PRODUCT FEATURE
 Woltmann Detachable Type.
 Dry-dial, Magnetic drive.
 Selected high quality material for steady & reliable characteristic, low head loss and enable use a long life span.
Vacuum sealed register ensures the dial kept free from fog and keep the reading clear in a long term service.
 Universal use within this range detachable, without removing the meter from the pipeline for easy maintenance
and replacement, good looking, etc.
 Hot water meter and remote reading transmission system for option.
INSTALLATION REǪUIREMENTS
1. The meter should be installed in horizontal position with the register face upwards
2. Pipeline must be flushed before installation.
3. The meter should be constantly full of water during operation.

MAXIMUM PERMISSIBLE ERROR
In the lower zone from Qmin inclusive up to butexcluding Qt is ±5%
In the upper zone from Qt indusive up to and including Qs is ±2%
(Hot Water Meter ±3%)
WORKING CONDITION
Water temperature: 0°C≤t≤40°C (for cold water meter)
0°C≤t≤90°C (for hot water meter)
