Jual Gas Turbine Flow Meter SHM Size 2 1/2 Inch
Informasi Produk
Spesifikasi :
APPLICATION
Natural Gas, City Gas, Propane, Butane, Air, Nitrogen, and other gases.
Gas Turbine Flow Meter SHM Size 2 1/2 Inch ( DN 65mm )
Tersedia dan siap dikirim
Jual Gas Turbine Flow Meter SHM Size 2 1/2 Inch
Gas Turbine Flow Meter SHM
SPECIFICATION
Size : DN 25-300
Material : Head Epoxy Coated Aluminium Body Epoxy Coated Aluminium Flange Epoxy Coated Aluminium.
Temperature : (-20) -60c
Pressure : 16 Bar
Power Supply : Battery 3.6 V/ 24 VCD
Output : Pulse, 4-20 mA, RS 485
Protecction Grade : IP 65
Connection : PN 16
Accuracy : +/-1.5%
Measurement : Refer to Table below
Repeatibility : -
Explosion Proof :-
Waranty 2 years ( full Service & Spare parts )
APPLICATION
Natural Gas, City Gas, Propane, Butane, Air, Nitrogen, and other gases.
